- Perform at your best with 1000W of power
- Modular connections with 12V-2 × 6 support
- 105°C Japanese Capacitors and 80 PLUS Gold Certified and Cybenetics Platinum Certified
- Zero RPM Mode and Fluid Dynamic Fan
Technical Specifications
x| Spec Sheet | OMEN 1000W Power Supply - ATX 3.1 Fully Modular 80 Plus Gold |
| What's in the box | OMEN 1000W Power Supply - ATX 3.1 Fully Modular 80 Plus Gold; Power cable; Cable bag; 4 x screws; 9 x Cable ties; 2 x EPS/ATX12V cable 8-pin (4 + 4); 2 x PCIe cable 8-pin (6 + 2); 1 x 12V-6x2 cable; 1 x SATA cable (4 right); 2 x SATA cable (3 right); 1 x ATX cable 24-pin; 1 x PATA cable (3 right and 1 straight); HP Installation Guide (QR code for YouTube) |
| Connector description | 2 EPS connectors; 1 ATX connector; 6 SATA connectors; 4 PATA connectors; 2 PCIe connectors |
| Weight | 2.53 kg (Package: 2.8 kg) |
| Dimensions (W x D x H) | 150 x 160 x 86 mm |
| Package dimensions | 320 x 195 x 125 mm |
| Power supply type | 1000 W 80 Plus Gold certified ATX 3.1 fully modular power supply |
| Power output maximum | +3.3V/+5V, combined shall not exceed 150 W, total 1000 W |
| Input voltage | 100 - 240 V AC, 50/60 Hz, 12A - 6A; +3.3V DC/20A; +5V DC/20A; +12V DC/82A; +5V SB/3A |
| Manufacturer Warranty | HP ten-year limited warranty |
| Product safety | View Safety Document |
| Special features | Japanese capacitors 105°C; Modern standby; Cybenetics Platinum Efficiency |
| Fan bearing / Size | Fluid Dynamic Bearing (FDB); 135 mm |
| Fan noise / Speed | 0 dB @ zero RPM mode; <28 dBA @ max load; 0 - 1100 RPM±10% |
| Spec Sheet | OMEN 1000W ATX 3.1 PSU (Full Specifications) |
| What's in the box | OMEN 1000W Power Supply - ATX 3.1 Fully Modular 80 Plus Gold; Power cable; Cable bag; 4 x screws; 9 x Cable ties; 2 x EPS/ATX12V cable 8-pin (4 + 4); 2 x PCIe cable 8-pin (6 + 2); 1 x 12V-6x2 cable; 1 x SATA cable (4 right); 2 x SATA cable (3 right); 1 x ATX cable 24-pin; 1 x PATA cable (3 right and 1 straight); HP Installation Guide (QR code for YouTube) |
| Connector description | 2 EPS connectors; 1 ATX connector; 6 SATA connectors; 4 PATA connectors; 2 PCIe connectors |
| Weight | 2.53 kg (Package: 2.8 kg) |
| Dimensions (W x D x H) | 150 x 160 x 86 mm |
| Package dimensions | 320 x 195 x 125 mm |
| Power supply type | 1000 W 80 Plus Gold certified ATX 3.1 fully modular power supply |
| Power output maximum | +3.3V/+5V, combined shall not exceed 150 W, total 1000 W |
| Input voltage | 100 - 240 V AC, 50/60 Hz, 12A - 6A; +3.3V DC/20A; +5V DC/20A; +12V DC/82A; +5V SB/3A |
| Manufacturer Warranty | HP ten-year limited warranty |
| Product safety | View Safety Document |
| Special features | Japanese capacitors 105°C; Modern standby; Cybenetics Platinum Efficiency |
| Fan bearing / Size | Fluid Dynamic Bearing (FDB); 135 mm |
| Fan noise / Speed | 0 dB @ zero RPM mode; <28 dBA @ max load; 0 - 1100 RPM±10% |
